食物切碎机-上海不锈钢食物切碎机-商用食物切碎机-上海恒联食物切碎机-上海食物切碎机销售-上海食物切碎机价格-恒联食物切碎机QS630
主要特点
恒联食物切碎机是专门为肉菜类食物切碎而设计的食品加工机械。该机能快速地将肉、蔬菜瓜果等食物切碎，用以制作馅料。它采用蜗轮。蜗杆减速传动，结构紧凑，具有操作方便，工作效率高的特点。并设保护装置，安全可靠，凡接触食物的零件均采用电蚀铝合金或不锈钢制作，外形美观，符合卫生标准，是宾馆、酒楼、集体食堂和食品加工厂等理想的加工设备
TQ8为喷涂集体，TQ8A为铝镁合金集体。
H.L Food Cutting Machine is specially designed for cutting meat and vegetables It can cut meat vegetable melon and fruit rapidly to make fillings The machine is driven by worm wheels and worm-type speed-down gears The machine has the characteristics of compact structure, fine appearance easy operation and high efficiency The machine is equipped with a protective device that makes the operation more safe and reliable All parts that contact the food directly are made of anti-corrosion Al alloy and stainless steel which are endurable in use and in conformity with national food hygienic standard Model TQ8 has coated body and model TQ8 A has aluminum-magnesium alloy body.
TQ-8/TQ8A外壳喷漆/外壳抛光
Painted body /Polished body
QS620A/QS620B外壳喷漆/外壳不锈钢
Painted body /Stainless steel body
TQ-5/TQ-5A外壳喷漆/外壳抛光
Painted body /Polished body
技术参数Technical Specifications
|
型号 Model |
额定电压Rated Voltage |
整机重量 Net Weight |
电机功率Power |
料桶容积 Capacity |
额定频率 Frequency |
生产能力 Production capacity |
外形尺寸 Dimension |
|
TQ-5/TQ-5A |
220 |
62 |
0.37 |
5 |
50 |
80 |
525*420*550 |
|
TQ-8/TQ8A |
220 |
90 |
0.75 |
8 |
50 |
120 |
800*550*550 |
|
QS620B/QS620A |
220/380 |
126 |
1.5/1.1 |
20 |
50 |
120 |
775*710*940 |
|
QS630 |
380 |
318 |
2.2/2.8 |
25 |
50 |
300 |
990*810*980 |
|
QS650 |
380 |
360 |
2.2/2.8 |
50 |
50 |
1000 |
1200*1000*1138 |
